| Product Attribute | Attribute Value |
|---|---|
| Approvals | UL Recognized |
| Connection Type | Screw |
| Cut Out, Panel | 1/32 DIN |
| Dimensions | 1.89" L x 1.88" W x 0.94" H |
| Dimensions, Cutout, Inches | 1⁄32 DIN in. |
| Display | LCD |
| Display Digit Height | 8 mm |
| Display Type | Digital, LCD |
| Function | Timer |
| Height | 1.57 Inch |
| Input Type | Voltage |
| Length | 2.11 Inch |
| Measurement Range | 0 to 99999.9 hr. |
| Measuring Range | 0 to 99999.9 hrs. |
| Mounting Type | 1/32 DIN rail |
| Number of Digits | 8 Digits |
| Primary Type | Electronic |
| Product Header | Hours/Minute 8-Digit LCD Timer |
| Series | |
| Size | 24 x 48 mm |
| Supply Voltage | 10 to 250 V V |
| Type | High voltage |
| UPC Code | 786685114491 |
| Weight | .17 Pound |
| Width | 2.2 Inch |
