| Product Attribute | Attribute Value |
|---|---|
| Enclosure Rating | IP40 |
| Input Type | Voltage |
| Mounting Type | DIN Rail |
| Series | |
| Supply Voltage | 100 to 240 VAC |
| Termination | Blade |
| Type | Timer |
Overview
Specifications Input Voltages: 120-240 VAC 10% to –20% (50/60 Hz); 12 VDC, ±10%; 24 VAC/VDC, 10% to –15%. Contact Configuration: 2 Form C, DPDT (delay outputs). Contact Load Ratings: 10 A resist. @ 240 VAC, 30 VDC; 7 A inductive @ 240 VAC, 30 VDC; 1⁄6 HP @ 120 VAC; 1⁄3 HP @ 240 VAC. Power Consumption: 2.2 VA, maximum. Repeat Accuracy: ±0.25% maximum, 10 ms. Reset Time: 0.1 second, maximum. Dielectric Strength: 1500 VAC, 1 minute (between power and output terminal, except between contacts of the same pole). Life Expectancy: Mechanical — 50,000,000 operations; Electrical 250,000 operations. Features:
