| Product Attribute | Attribute Value |
|---|---|
| Approvals | CE Compliant, UL, cUL recognized |
| Connection Type | Terminal |
| Cut Out, Panel | 1/32 DIN |
| Depth | 0.079" (2mm) |
| Dimensions, Cutout, Inches | 45.5 x 22.6 mm |
| Display Digit Height | 8 mm |
| Display Type | Digital, LCD |
| Function | Hour Meter |
| Input Signal Type | 10-300 VDC/20-300 VAC |
| Input Type | Voltage |
| Meter Type | Hour |
| Minimum Operating Temperature | -10 °C |
| Mounting Type | Panel |
| Number of Digits | 8 Digits |
| Series | |
| Special Features | Front Panel Reset Only |
| Supply Voltage | 10 to 300 VDC VDC |
| Temperature Range | -10 to 60 °C |
| Temperature, Opening, Maximum | 60 °C |
| Type | Electronic |
Overview
Features:
