| Product Attribute | Attribute Value |
|---|---|
| Accuracy | ±0.02% % |
| Approvals | CSA Recognized, UL |
| Connection Type | Blade Terminal |
| Dimensions, Cutout, Inches | 2 (Dia.) in. |
| Display Digit Height | 3 mm |
| Display Type | Digital |
| Function | Hour Meter |
| Input Type | Voltage |
| Material, Casing | Polyester |
| Measurement Range | 0 to 10000 hr. |
| Measuring Range | 0 to 10000 hrs. |
| Minimum Operating Temperature | -40 °C |
| Mounting Type | Panel |
| Number of Digits | 6 Digits |
| Primary Type | Electromechanical |
| Product Header | 85000 Series DC Hour Meters |
| Series | |
| Supply Voltage | 10 to 80 VDC VDC |
| Temperature Range | -40 to 85 °C |
| Temperature, Opening, Maximum | 85 °C |
| Type | Electromechanical |
Overview
The 85000 Series of DC hour meters from Honeywell indicates when it is time to service equipment, helping you decrease downtime and increase maintenance efficiency. A technically advanced quartz package provides a highly reliable drive mechanism, an improved odometer gear train, and a snap-together integrated chassis. Every Quartz Plus meter passes 100% function, burn-in, and timing accuracy tests before shipping.
DC Hour Meters from Honeywell feature:
